| Inverter Power Supply
|
The IP power frequency inverter is the core of the Cintrong company's new generation 32 bit processor ARM, IGBT is the executive component, and the isolation transformer is designed for voltage conversion.
The IP power frequency inverter uses the DC-AC (DC - AC) mode to convert the input power into any power supply in the world through the SPWM (sinusoidal pulse width modulation) transformation to meet the needs of different voltages and frequencies. |
|
 ARM-32 bit microprocessor control is reliable, stable and intelligent.  Dynamic response and fast speed. Three phase vector control and three phase voltage automatic balance High precision. High frequency and high stability. 7 Inch Touch screen display and control, beautiful interface, multi parameter display. Power frequency transformer isolation, pure sine wave output of power frequency inverter. RS232 communication interface, standard MODBUS-RTU protocol, can turn CAN, TCP/IP interface, through mobile phone APP remote view and control. Input parameters | Name | Idex | Remarks |
Rated voltage
| DC36V-72V
DC90V-180V
DC190V-380V
DC380V-690V | Optional any voltage, acceptable non - standard customization | Confluence | Multi loop optional | can be customized
| Input switch | DC MCB switch
| |
Output parameters | Name | Idex | Remarks | Modulation mode | IGBT/SPWM | | Output voltage | three phase 380V/400V/, single phase 220V/230V | Customizable output voltage
| Output voltage stability (average) | ±1%（Customizable higher precision） | | Reaction time | 2mS（for input voltage） | | Stable time | <50MS back to less than 5% | | Voltage waveform distortionTHD | < 2%（linear load） | | Output frequency
| 50HZ/60HZ | | Frequency stability | < 0.1% | | Phase shift | Load three phase equilibrium or no-loadis ≤±1°；100% three phase unbalance：≤±4° | | Three phase imbalances | Automatic balance of three-phase voltage | | Isolation transformer | △/Y | |
Control parameters | Name | Idex | Remarks |
Main control element
| he main measurement and control chip is ARM32 bit processor, and the inverter is IGBT. | | Carrier frequency | 4K;8K;12K;16K optional
| | Control voltage and current acquisition mode | Value of validity | | Control mode | Voltage closed loop control or current closed loop control or VF curve control. | | Interface | RS232，MODBUS-RTU protocal | Optional RS485，CAN，TCP/IP，GPRS |
Display parameters | Name | Idex | Remarks | Display medium | 7 inch touch screen or 192*64（LCD） | |
Display rated parameters | Input voltage and current;
Output three-phase voltage and frequency;
The average value of output line voltage;
Output power factor;
Output three-phase current;
Output active power, apparent power | |
Display alarm content
| Fuse break, high IGBT temperature, high transformer temperature, IGBT fault, overload, undervoltage and so on. | | Rated parameter display precision | 1.0 grade | | Voltage parameter resolution | 0.1V | Customizable higher resolution | Current parameter resolution | 0.1A | Customizable higher resolution |
Protection parameters | Name | Idex | Remarks |
Protective species
| Input no fuse switch, output no fuse switch, electronic circuit to detect overcurrent, overvoltage, overload, high temperature, IGBT alarm, fuse alarm, short circuit and automatic jump off protection and alarm | | Protection mode | Cut off the output | |
Physical parameters | Name | Idex | Remarks | Heat dissipation mode | Natural cooling or forced air cooling | | Protection grade | Indoor IP21; outdoor IP23 or higher level | |
Name composition
Three phase model
| Model | Capacity(kVA) | Output current(A) | Dimension
W×D×H(mm) | IPD3-003 | 3 | 4.6 | 350×650×670
(with wheels) | IPD3-006 | 6 | 9.1 | IPD3-010 | 10 | 15.2 | IPD3-015 | 15 | 22.8 | 460×700×1170
(with wheels) | IPD3-020 | 20 | 30.4 | IPD3-030 | 30 | 45.6 | IPD3-045 | 45 | 68.4 | 780×650×1450 | IPD3-060 | 60 | 91.2 | IPD3-075 | 75 | 114.0 | 950×700×1600 | IPD3-090 | 90 | 136.7 | IPD3-120 | 120 | 182.3 | IPD3-150 | 150 | 227.9 | 1200×750×1800 | IPD3-200 | 200 | 303.9 | IPD3-250 | 250 | 379.8 | 1400×800×2000 | IPD3-300 | 300 | 455.8 | IPD3-350 | 350 | 531.8 | 1500×1050×2200 | IPD3-400 | 400 | 607.8 | IPD3-500 | 500 | 759.7 | 2400×1200×2200 | IPD3-600 | 600 | 911.6 | IPD3-800 | 800 | 1215.5 | 1500×1050×2200 two enclosures | IPD3-1000 | 1000 | 1519.4 | 1500×1050×2200 three encolsures | IPD3-1200 | 1200 | 1823.3 | Note: dimension and protection grade can be customized. Single phase model | Model | Capacity(kVA) | Output current(A) | Dimension
W×D×H(mm) | IPD1--500W | 0.5 | 2.3 | 425×436×173
| IPD1-001 | 1 | 4.5 | IPD1-002 | 2 | 9.1 | 350×650×670
(with wheels) | IPD1-003 | 3 | 13.6 | IPD1-005 | 5 | 22.7 | IPD1-010 | 10 | 45.5 | IPD1-015 | 15 | 68.2 | 460×700×1170
(with wheels) | IPD1-020 | 20 | 90.9 | IPD1-030 | 30 | 136.4 | IPD1-045 | 45 | 204.5 | 780×650×1450 | IPD1-060 | 60 | 272.7 | IPD1-075 | 75 | 340.9 | 950×700×1600 | IPD1-090 | 90 | 409.1 | IPD1-120 | 120 | 545.5 | 1200×750×1800 | IPD1-150 | 150 | 681.8 | IPD1-200 | 200 | 909.1 | 1400×800×2000 | IPD1-300 | 300 | 1363.6 | Note: dimension and protection grade can be customized. Smart micro grid, energy storage inverter, photovoltaic, wind power, energy recovery, communication, power inverter power, etc.
|
|
|
