Uninterruptible Power Supply

Publication time : 2020-3-11 11:26:38　

Main functions:
Provide uninterruptible AC Power Supply. Pure online type, online interactive type, backup type, power frequency machine, high frequency machine, module machine are available.

Scope of application:
Server room, communication, education, fire fighting, bank and other important places where power cannot be cut off.

Features
Parameters
Specification
Application

Dual input: standard installation of one or two independent power supplies is allowed

Automatic internal bypass: built in 100% rated bypass static switch, which allows the load to be transferred from the mains supply to prevent power failure in case of serious overload

Parallel 1 + 1 redundancy: connected equipment can be powered by two parallel UPS to increase system redundancy

Strong and durable design: the internal circuit board is protected by special coating, equipped with IP21 protection grade and dust filter net, which can better resist harsh environment

Built in transformer: it can be configured as bypass transformer or output transformer on site to realize complete electrical isolation and strengthen load protection

Powerful charger: an overall solution that can meet most backup time requirements, and can be applied to super capacitor or lithium battery

Industrial Design: support 100% non-linear / unbalanced load and provide genset compatibility

Manual maintenance bypass: easy to operate maintenance bypass, which allows complete isolation of all parts of the system, and supports maintenance operation at the same time of continuous power supply

Front and back maintenance: power device maintenance only needs to open the front and rear doors, and PCB board is installed on the top of the equipment. Meet the needs of parallel cabinets on both sides.

Input power factor correction: cable, breaker and generator do not need to be too large

Intelligent battery maintenance calendar: self defined maintenance calendar, full-automatic charge and discharge management on time, to prevent the battery from aging in advance, and extend the battery life

Multiple operation modes: online, online interactive (ECO) and backup optional functions are provided, and operation modes are selected according to the load demand to save energy and reduce consumption.

Easy to install: equipped with casters for easy movement, all cable connectors are easy to identify, saving installation time

Power on Wizard: step-by-step guidance and intuitive menu display for easy setup and system navigation

Flexible communication options: equipped with dry node, MODBUS and SNMP network card, supporting remote and local monitoring and management

User friendly graphic interface: easy to view LCD display, supporting analog diagram, sound alarm and multi language display, easy to operate

Rated power	10-300kVA
System optional voltage	200/220/380/400/415V/440/690V
System frequency	45-65HZ
Rectifier input
Input voltage（V）	System voltage (three-phase + N)
Frequency（Hz）	45-65Hz
Soft start	0-100%，10s
Input power factor	0.8（Add harmonic compensation module>0.95）
THDI	30%（Add harmonic compensation module＜5%）
Input voltage range of mains supply	-15% to +20%
Rectifier output
Output voltage（V）	Can be set (according to battery pack parameters)
Charging current	Can be set (according to battery pack parameters)
Ripple voltage	＜1%
Battery
Charging voltage	Can be set (according to battery pack parameters)
Charging current	Can be set (according to battery pack parameters)
Battery maintenance calendar	4 periods can be set
Inverter output
Rated output voltage（V）	Can be set according to the system voltage
Phases	3+N
Full load efficiency (online)	Max 91%
Linear load distortion	3%
Voltage phase shift during load balancing (degree)	±1º
Voltage phase shift in unbalanced load (degree)	±2º
Voltage unbalance during load balancing	±1%
Voltage unbalance at 100% load unbalance	±3%
Non linear load distortion (peak factor 3:1)	5%
Steady state voltage stability	±1%
Transient voltage range and response recovery time	±10% into 10ms
Rated frequency	Same as input
Frequency stability	Synchronous: same as bypass frequency; Asynchronous: ±0.05%
Overload	110% rated current 300min 125% rated current 10min 150% rated current 1min
0.1s short circuit current	2 times input current
Bypass
Rated voltage	Can be set according to the system voltage
Phases	3+N
Input voltage range	±15% ( +20%-30% can be set)
Rated frequency	50/60Hz (automatic recognition)
Input frequency range	±2% (±5% can be set)
Inverter / bypass conversion time (overload)	0ms
Inverter / bypass conversion time (inverter failure)	1ms
Communication and management
Communication interface	Standard RS485
Display control panel	7 inch touch screen
Environmental protection
Working temperature	-10℃ to 40℃（Depending on the load status）
Relative humidity	0-90% non-condensing
Working altitude	It can run at full load at 0-1000m, and it should be derated if it exceeds
Noise (> 1m)	At full load<54 dB
Protection level	IP21

Power（kVA）	UPS size（H×W×D）mm	Weight（kg）
10	350×650×630	150
15	460×650×1200	210
20		260
30		310
40	780×650×1350	365
50		382
60		398
80	950×700×1500	512
100		550
120		566
160	1200×750×1800	875
200	1200×750×1800	980
250	1400×1000×2100	1800
300	1400×1000×2100	2100

Note: parallel connection structure of high-power.

Industrial process control (semiconductor, automobile, etc.), transportation (subway, railway, etc.), infrastructure, medical / hospital, water plant, mine
